SX5-8202021

Brand: Dongfeng

Model: FMC SX5

Product Name：Rear View Mirror Left

Part Number: SX5-8202021

Contact Now WhatsApp

Product Details

Dongfeng FMC SX5 Rear View Mirror (Left, Part No.: SX5-8202021)

Think of this as your Dongfeng FMC SX5’s “left-side road observer”—not just a glass mirror in a plastic case, but a critical exterior safety component that gives you a clear view of the rear-left traffic, pedestrians, and obstacles, making lane changes, parking, and reversing safer. It’s a multi-functional, durable assembly designed to handle daily use and harsh weather while blending with the SX5’s side styling.

At its core, it includes key elements: a high-impact ABS plastic housing (resists cracks from minor scrapes or wind pressure), a shatterproof glass mirror (either manual or electric adjustment), a heating element (optional—defrosts fog/ice in cold weather), and a mounting base (secures to the SX5’s left door). For electric models, it also has a small motor and wiring harness (connects to the dashboard switch for easy angle adjustment). Mounted on the left front door—positioned to give the driver a wide, unobstructed view of the rear-left lane—it eliminates blind spots and helps you make quick, safe judgments on the road.

Without this left rear view mirror, the SX5’s driver would lose critical visibility of the rear-left area—lane changes would be risky (you might miss oncoming vehicles in the blind spot), and parking/reversing could lead to collisions with curbs or other objects. Dongfeng tailored its size, mirror curvature, and mounting position to the SX5’s driver seat height and door design—ensuring the view is optimized for comfort and safety. A generic mirror would either not fit the SX5’s door, have a wrong curvature (distorting the view), or lack features like heating (useless in cold weather).

 Core Jobs: Expand Visibility, Ensure Safety, and Adapt to Weather

As a safety-focused exterior part for the FMC SX5, it has three non-negotiable roles:

Blind Spot Elimination: The mirror’s curved glass (or flat glass, depending on configuration) provides a wide view of the rear-left lane—covering areas the driver can’t see with their peripheral vision, reducing lane-change collision risks.

Adjustable View: Manual or electric adjustment lets the driver tweak the mirror angle to match their height and seating position—ensuring a clear, personalized view every time. Electric models even let you adjust from the dashboard (no need to reach outside).

Weather Adaptation: Optional heating elements melt fog, ice, or dew on the mirror glass in cold/wet weather—keeping the view clear, while the waterproof housing prevents water from seeping inside and damaging internal parts.

This left rear view mirror is exclusive to Dongfeng FMC SX5—wrong fit means poor visibility or damage:

Fits: All Dongfeng FMC SX5 variants (matches door mounting points, mirror size, and electrical specs—confirm via VIN; note if your SX5 uses manual or electric mirrors).

Won’t Fit:

Other Dongfeng models: Like H30, AX3, or Dignity ix5—different door designs, mirror sizes, or electrical setups (mirror won’t attach or adjustment won’t work).

Non-Dongfeng vehicles: Even if the shape looks similar, their door mounting holes and mirror curvature differ (no functional fit—distorted view or loose attachment).

Dongfeng FMC SX5’s right side: Left and right mirrors are mirror images (different mounting bases and glass curvature)—this part is for the left only (right side needs a different part number).

 Installation & Maintenance (DIY-Friendly for Manual; Pro for Electric)

Installation: 30–45 Minutes (Manual: Screwdriver; Electric: Additional Wiring Tools)

For Manual Mirrors:

Prep: Remove the plastic cover inside the SX5’s left door (to access mirror mounting screws).

Remove Old Mirror: Unscrew the bolts holding the old mirror to the door, then disconnect any wiring (if heated). Pull the old mirror off.

Install New Mirror: Align SX5-8202021 with the door’s mounting holes, secure with bolts, and reattach the door cover.

For Electric/Heated Mirrors:

Follow steps above, but extra care: Disconnect the battery first (avoids electrical shocks). Match the new mirror’s wiring harness to the door’s existing connector (don’t mix up wires).

Test: Reconnect the battery and check if electric adjustment/heating works before reattaching the door cover.

Maintenance: Keep It Clear and Secure

Weekly Cleaning: Wipe the mirror glass with a soft cloth and glass cleaner to remove dirt, bug guts, or road salt—dirty mirrors reduce visibility by 40–50%.

Monthly Inspection: Check the housing for cracks, the mounting screws for tightness, and (for electric models) the adjustment motor for smooth operation—tighten loose screws or replace damaged parts early.

Heating Element Check (Winter): Test the heater before cold weather hits—if it doesn’t melt ice, check the wiring or fuse (common issues are loose connections).

Avoid Harsh Impacts: Don’t push or pull the mirror forcefully (e.g., when parking too close)—this can break the adjustment mechanism or crack the housing.

Brief Summary: Dongfeng FMC SX5 Left Rear View Mirror (Part No.: SX5-8202021)

A critical exterior safety part for Dongfeng FMC SX5, this left rear view mirror acts as a "left-side road observer," offering clear rear-left visibility for safer lane changes, parking, and reversing. It’s a durable assembly with high-impact ABS housing (weather/impact-resistant), shatterproof glass (curved/flat), optional heating element (defrosts fog/ice), and mounting base—electric models add an adjustment motor and wiring.

Core roles: eliminate blind spots via wide view, enable manual/electric angle adjustment (dashboard control for electric), and adapt to weather (waterproof housing, optional heater). Without it, visibility is lost; generic mirrors fail in fit or function.

Fits all SX5 variants (confirm VIN; note manual/electric); won’t fit other Dongfeng models, non-Dongfeng cars, or SX5’s right side.

Installation takes 30–45 mins (DIY for manual, pro for electric). Maintain by weekly glass cleaning, monthly housing checks, and winter heater tests. Original parts avoid aftermarket risks (poor fit, distorted view).
